Hydraulic Valve Expertise: P120-G1-OT Directional Valve | Manufacturing & Supply

控制方式:手控

路数:1 联

额定流量:120 升/分钟 (31.7 美制加仑/分钟)

最大压力:250 bar (3600 psi)

进油口:G1接口

出油口:G1接口

接口尺寸:G1接口

品牌:BXHS

所属类别:单块式方向阀

产品系列:P120系列单块式方向阀

Packagingsize:19*35*16

Grossweight:13.60 kg

库存: 有货

描述

Hydraulic Valve Expertise: P120-G1-OT Directional Valve | Manufacturing & Supply

Hydraulic Valve Expertise: P120-G1-OT Directional Valve | Manufacturing & Supply drawing image

The P120-G1-OT Directional Valve is a high-performance hydraulic valve designed for use in a wide range of industrial applications. With its manual control, 1 section, and monoblock valve design, this valve offers precise control and durability. Its 120 L/min rated flow and 250 bar max pressure make it suitable for demanding applications in industries such as material handling, construction, agriculture, and industrial vehicles.

P120系列单块式方向阀参数
控制方式	手控, 软轴, 一控二手柄控制, 手控+一控二
路数	1 联, 2 联, 3 联, 4 联
额定流量	120 升/分钟 (31.7 美制加仑/分钟)
最大压力	250 bar (3600 psi)
进油口	G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 3/4 NPT螺纹, 1 NPT螺纹, M36×2螺纹
出油口	G1接口, SAE 16接头, 1 NPT螺纹, M36×2螺纹
接口尺寸	G3/4接口, G1接口, M27×2.0螺纹, SAE 14接头, SAE 16接头, 1 NPT螺纹, M36×2螺纹
联数	1联, 2联, 3联, 4联
结构类型	整体阀
环境温度范围	-40°C to +80°C (-40°F to +176°F)
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)

**P120-G1-OT Directional Valve**

**Features:**

- Manual control
- 1 section
- Monoblock valve design
- 120 L/min rated flow
- 250 bar max pressure
- Operating viscosity range: 15 - 75 mm²/s (15 cSt to 75 cSt)
- Ambient temperature range: -40°C to +80°C (-40°F to +176°F)
- 1 spool
- P120 Series

**Applications:**

- MATERIAL HANDLING
- CONSTRUCTION AND EARTH MOVING
- AGRICULTURE
- INDUSTRIAL VEHICLES

**Applicable Models:**

- TELEHANDLER
- FORKLIFT
- ALL TERRAIN CRANE
- STACKER
- AERIAL PLATFORM
- MOTOR GRADER
- MINI-EXCAVATOR
- SKID STEER LOADER
- WHEEL LOADER
- HARVESTER
- BALE WRAPPER
- SEEDING MACHINE
