This heavy-duty 6 cc/rev hydraulic gear pump, manufactured in China, is designed for high-performance applications in construction, agriculture, and industrial vehicles. With a displacement of 10 cc/rev, 20 MPa rated pressure, and 2000 r/min rated speed, it delivers reliable power and efficiency.
| CBHS-FL3系列 液压齿轮泵 参数 | |
|---|---|
| 排量 | 10 毫升/转, 4 毫升/转, 20 毫升/转, 16 毫升/转, 14 毫升/转, 6 毫升/转 |
| 额定压力 | 20 MPa (2900 psi) |
| 最大压力 | 25 MPa (3625 psi) |
| 额定转速 | 2000 r/min |
| 最大转速 | 3000 r/min |
| 旋转方向 | 左旋（逆时针旋转）, 右旋（顺时针旋转） |
| 材质 | 铝 |
| 架构 | 外啮合齿轮泵 |
| 法兰盘类型 | A-菱形法兰 |
| 轴伸形式 | H:矩形花键, X:渐开线花键, P：普通键 |
The CBHS-FL3 Series hydraulic gear pump features a robust internal gear design and is constructed from durable aluminum. It offers a rated pressure of 20 MPa (2900 psi) and a rated speed of 2000 r/min, with a maximum speed of 3000 r/min. The pump is available with left or right rotation options and comes with an A-oval flange and plain key shaft. Its versatility makes it suitable for a wide range of applications, including telehandlers, forklifts, mini-excavators, skid steer loaders, compact wheel loaders, tractors, front-end loaders, harvesters, balers, and sprayers.
