Our factory directly supplies high-quality P80 series directional hydraulic valves for various applications, including material handling, construction, agriculture, and industrial vehicles. These solenoid-controlled, monoblock valves offer a rated flow of 80 L/min and a max pressure of 250 bar, perfect for telehandlers, forklifts, cranes, stackers, and more. Contact us for OEM, ODM, customization, and wholesale inquiries.
| P80系列 单块式方向阀 参数 | |
|---|---|
| 控制方式 | 手控, 气控, 电气控, 电液控, 电磁, 液控, 液控和手控, 软轴, 一控二手柄控制, 手控+一控二 |
| 路数 | 1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联 |
| 环境温度范围 | -40°C to +80°C (-40°F to +176°F) |
| 结构类型 | 整体阀 |
| 联数 | 1联, 2联, 3联, 4联, 5联, 6联, 7联 |
| 工作粘度范围 | 15 - 75 mm²/s (15 cSt to 75 cSt) |
| 额定流量 | 80 L/min (21.2 US gpm) |
| 最大压力 | 315 bar (4600 psi) |
| 进油口 | G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
| 出油口 | G1/2接口, G3/4接口, M27×2.0螺纹, SAE 10接头, SAE 12接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
| 接口尺寸 | G1/2接口, G3/4接口, M22×1.5螺纹, M27×2.0螺纹, SAE 10接头, 1/2 NPT螺纹, 3/4 NPT螺纹 |
We are a hydraulic product manufacturer specializing in the production of high-quality P80 series directional hydraulic valves. Our factory directly supplies these valves to global markets, offering manufacturing, OEM, ODM, customization, and wholesale options. We also welcome inquiries from distributors, wholesalers, agents, and traders. Our P80 valves are solenoid-controlled, monoblock valves with a 3-section design. They offer a rated flow of 80 L/min (21.2 US gpm) and a max pressure of 250 bar (3600 psi). The operating viscosity range is 15 - 75 mm²/s (15 cSt to 75 cSt) and the ambient temperature range is -40°C to +80°C (-40°F to +176°F). These valves feature a 3-spool design and are ideal for a wide range of applications, including material handling, construction and earth moving, agriculture, and industrial vehicles. They are compatible with various models such as telehandlers, forklifts, all-terrain cranes, stackers, aerial platforms, motor graders, midi-excavators, mini-excavators, skid steer loaders, and compact wheel loaders. By choosing our factory direct supply, you benefit from competitive pricing, superior quality, and fast delivery. Contact us today to discuss your specific requirements and explore our customized solutions.
