Directional Valve Types Control Fluid Power with Confidence: HSDSL Electric and Manual Valves

控制方式:电比例+手控

路数:6 联

额定流量:140 L/min (37 US gpm)

最大压力:250 bar (3600 psi)

进油口:G3/4接口

出油口:G3/4接口

接口尺寸:G1/2接口

品牌:BXHS

所属类别:比例控制阀

产品系列:HSDSL系列比例控制阀

Packagingsize:48*30*18

Grossweight:35.00 kg

库存: 有货

描述

Directional Valve Types Control Fluid Power with Confidence: HSDSL Electric and Manual Valves

Directional Valve Types Control Fluid Power with Confidence: HSDSL Electric and Manual Valves drawing image

The HSDSL Series Directional Valve is a high-performance, sectional valve designed for demanding applications in construction, material handling, and industrial vehicles. It features both electric proportional and manual control options, offering versatility and reliability for various operating environments.

HSDSL系列比例控制阀参数
控制方式	液控, 液控和手控, 电比例, 电比例+手控
路数	1 联, 2 联, 3 联, 4 联, 5 联, 6 联, 7 联, 8 联, 9 联, 10 联, 11 联, 12 联
额定流量	140 L/min (37 US gpm)
最大压力	250 bar (3600 psi)
进油口	G3/4接口
出油口	G3/4接口
接口尺寸	G1/2接口
联数	1联, 2联, 3联, 4联, 5联, 6联, 7联, 8联, 9联, 10联, 11联, 12联
结构类型	分片阀
环境温度范围	-40°C to +80°C (-40°F to +176°F)
工作粘度范围	15 - 75 mm²/s (15 cSt to 75 cSt)

The HSDSL Series Directional Valve is a 6-section, high-flow, high-pressure valve capable of handling up to 140 L/min (37 US gpm) with a maximum pressure rating of 350 bar (5100 psi). It is suitable for a wide range of operating viscosities (15-75 mm²/s) and ambient temperatures (-40°C to +80°C). The valve features 6 spools, offering precise control of fluid flow. This series is ideal for various applications, including telehandlers, forklifts, cranes, stackers, aerial platforms, motor graders, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, and dumpers.
