Tipping Pump CBHST1-UNI-63 Hydraulic Gear Pump: Factory Direct Supply & Global Distribution

排量:63 毫升/转

额定压力:22 MPa (3190 psi)

最大压力:25 MPa (3625 psi)

最大转速:2500 r/min

旋转方向:双向

品牌:BXHS

所属类别:液压齿轮泵

产品系列:CBHST1-UNI系列液压齿轮泵

Packagingsize:34*17*17

Grossweight:18.20 kg

库存: 有货

描述

Tipping Pump CBHST1-UNI-63 Hydraulic Gear Pump: Factory Direct Supply & Global Distribution

Tipping Pump CBHST1-UNI-63 Hydraulic Gear Pump: Factory Direct Supply & Global Distribution drawing image

High-quality CBHST1-UNI-63 Hydraulic Gear Pump for global markets. Factory direct supply and support for distributors, wholesalers, agents, and traders. Customize and OEM services available.

CBHST1-UNI系列液压齿轮泵参数
排量	32 毫升/转, 40 毫升/转, 50 毫升/转, 63 毫升/转, 80 毫升/转, 100 毫升/转, 34 毫升/转, 43 毫升/转
额定压力	23 MPa (3335 psi)
最大压力	25 MPa (3625 psi)
额定转速	2000 r/min
最大转速	2500 r/min
旋转方向	双向
架构	外啮合齿轮泵
材质	铸铁
轴伸形式	H:矩形花键, X:渐开线花键
法兰盘类型	UNI-3 安装孔

CBHST1-UNI-63 Hydraulic Gear Pump with customizable displacement (32 cc/rev to 100 cc/rev), rated pressure (23 MPa), and max speed (2000 r/min to 2500 r/min). Bidirectional rotation, swashplate structure, cast iron material, UNI-3 mounting holes, and options for rectangle spline and involute spline shaft types. Ideal for applications in material handling, construction, agriculture, and industrial vehicles. Trusted by manufacturers of telehandlers, forklifts, and other heavy machinery.
