Small Gear Pump 4 cc/rev Hydraulic Gear Pump - CBHS-FL304 | Factory Direct & Customizable

排量:4 毫升/转

额定压力:20 MPa (2900 psi)

最大压力:25 MPa (3625 psi)

最大转速:3000 r/min

旋转方向:右旋(顺时针旋转)

品牌:BXHS

所属类别:液压齿轮泵

产品系列:CBHS-FL3系列 液压齿轮泵

Packagingsize:20*30*20

Grossweight:9.00 kg

库存: 有货

1481 次查看了此产品

Small Gear Pump 4 cc/rev Hydraulic Gear Pump - CBHS-FL304 | Factory Direct & Customizable

Small Gear Pump 4 cc/rev Hydraulic Gear Pump - CBHS-FL304 | Factory Direct & Customizable

Small Gear Pump 4 cc/rev Hydraulic Gear Pump - CBHS-FL304 | Factory Direct & Customizable drawing image

The CBHS-FL304 4 cc/rev Hydraulic Gear Pump is a high-performance, durable pump designed for use in a wide range of applications, including construction, agriculture, industrial vehicles, and material handling. It is available in various configurations and is customizable to meet specific requirements.

CBHS-FL3系列 液压齿轮泵 参数
排量 10 毫升/转, 4 毫升/转, 20 毫升/转, 16 毫升/转, 14 毫升/转, 6 毫升/转
额定压力 20 MPa (2900 psi)
最大压力 25 MPa (3625 psi)
额定转速 2000 r/min
最大转速 3000 r/min
旋转方向 左旋(逆时针旋转), 右旋(顺时针旋转)
材质
架构 外啮合齿轮泵
法兰盘类型 A-菱形法兰
轴伸形式 H:矩形花键, X:渐开线花键, P:普通键

This CBHS-FL304 4 cc/rev Hydraulic Gear Pump is a robust and reliable component for various machinery. It is a factory direct product, meaning you are getting it straight from the manufacturer, ensuring competitive pricing and direct communication. Furthermore, the pump is customizable, allowing you to tailor it to your specific needs and application. The pump boasts a displacement of 10 cc/rev and a rated pressure of 20 MPa (2900 psi), making it suitable for demanding applications. Its rated speed is 2000 r/min with a maximum speed of 3000 r/min. The pump is available in both left and right rotation options. Constructed with an internal gear pump design using high-quality aluminium, it is durable and built to withstand demanding environments. The pump comes with an A-Oval Flange and Plain Key shaft for easy integration and compatibility with various machinery. The CBHS-FL304 pump is designed to be utilized in a wide array of machinery, including telehandlers, forklifts, mini-excavators, skid steer loaders, compact wheel loaders, wheel loaders, backhoe loaders, tractors and front-end loaders, harvesters, and balers. This versatile pump ensures its suitability across different applications within the construction, agriculture, industrial vehicles, and material handling sectors.
